Produktdetails:
|
| Anwendung: | Schutzbeschichtung für BMS-PCB und FPC von Batteriepacks für Elektrofahrzeuge | Heilungszustand: | 1500 mJ/cm² (UV) |
|---|---|---|---|
| Viskosität bei 25 °C: | 450 ± 150 mPa·s | Härte: | 73 Shore A |
| Farbe: | Bernstein transparent | Spannungsfestigkeit: | 23 kV/mm |
| Besonderheit: | Blaue Fluoreszenz für einfache Inspektion, geringer Geruch, geringe Reizung | Lagerbedingungen: | 6 Monate bei 8–28 °C |
| Verpackung: | 1kg / 5kg | ||
| Hervorheben: | UV cure adhesive for EV battery,Circuit board protection glue,Flexible printed circuits coating |
||
Circuit Board Protection Glue Description "Reliable protection, easy inspection." This circuit board protection glue (3200) is an amber transparent, solvent-free UV curing conformal coating specially developed for EV battery pack BMS boards and flexible printed circuits (FPC). It offers low hardness, low irritation and low odor for a friendly working environment, good adhesion to PCB substrates, plastics, glass and metal, and its blue fluorescence makes coating inspection
